■ A prevalent inverted T-shaped layout is in the base frame, which is high in rigidity of the integral structure and is not creative of any overturning during the full stroke
■ The base frame manufacture by five-sided machine high-precisely machining centre , finish most work in one chucking
■ A grouped 600 angular contact ball bearing 15 adopted in the lead screw , which 15 doubly supported and pre-tensioned ,50 as to increase the machining precision
■ High-frequency hardened slide rails or heavy- load high precision roller guide ways , which have an excellent property of shock absorption and can bear heavy load cutting
■ Taiwan precision spindle , 6000r / min and with air film protection device , so as to ensure to keep the spindle precision and service long life
■ CNC rotary table , Indexing table ,exchange table for optional
